A set of 4 safely carries up to 10,500 lb total.
We count 3 casters to be safe, since one can lift off uneven floors.
- Ships in 1–3 business days.
- 30-day easy returns
- Expert help, 920-204-6816.
Specifications
- Wheel material
- Polyurethane on cast iron
- Wheel diameter
- 12 in
- Wheel width
- 3 in
- Bearing
- Roller bearing
- Capacity
- 3,500 lb per caster
- Overall height
- 15-1/2 in
- Mounting
- Top plate
- Top plate size
- 5-1/4 x 7-1/4 in
- Bolt hole pattern
- 3-3/8 x 5-1/4 in, slotted to 4-1/8 x 6-1/8 in
- Attaching bolt size
- 1/2 in
- Finish
- Zinc
What these specs mean
Polyurethane on cast iron
A tough polyurethane tread on a cast iron core. Quiet, kind to floors and strong under heavy loads.
Roller bearing
Rolls well under heavy loads. Good for carts that move often.
Top plate 5-1/4 x 7-1/4 in
The flat plate that bolts under your cart. Measure your current plate to check the fit.
Overall height 15-1/2 in
From the floor to the top of the plate. Your cart sits this much higher.
