A set of 4 safely carries up to 1,650 lb total.
We count 3 casters to be safe, since one can lift off uneven floors.
- Ships in 1–3 business days.
- 30-day easy returns
- Expert help, 920-204-6816.
Specifications
- Wheel material
- Rubber on cast iron
- Wheel diameter
- 6 in
- Wheel width
- 2 in
- Bearing
- Roller bearing
- Capacity
- 550 lb per caster
- Overall height
- 7-1/2 in
- Mounting
- Top plate
- Top plate size
- 4-1/2 x 6-1/4 in
- Bolt hole pattern
- 2-7/16 x 4-15/16 in, slotted to 3-3/8 x 5-1/4 in
- Attaching bolt size
- 1/2 in
- Finish
- Zinc
What these specs mean
Rubber on cast iron
A rubber tread on a cast iron core. Quiet and gentle on floors, with a strong center.
Roller bearing
Rolls well under heavy loads. Good for carts that move often.
Top plate 4-1/2 x 6-1/4 in
The flat plate that bolts under your cart. Measure your current plate to check the fit.
Overall height 7-1/2 in
From the floor to the top of the plate. Your cart sits this much higher.
