A set of 4 safely carries up to 750 lb total.
We count 3 casters to be safe, since one can lift off uneven floors.
- Ships in 1–3 business days.
- 30-day easy returns
- Expert help, 920-204-6816.
Specifications
- Wheel material
- Polyurethane on polypropylene
- Wheel diameter
- 3-1/2 in
- Wheel width
- 1-1/4 in
- Bearing
- Delrin with delrin spanner bushing
- Capacity
- 250 lb per caster
- Overall height
- 4-3/4 in
- Mounting
- Top plate
- Top plate size
- 2-3/8 x 3-5/8 in
- Bolt hole pattern
- 1-3/4 x 2-7/8 in, slotted to 3 in
- Attaching bolt size
- 5/16 in
- Finish
- Stainless
What these specs mean
Polyurethane on polypropylene
A polyurethane tread on a plastic core. Quiet, kind to floors and will not rust.
Delrin with delrin spanner bushing
A plastic bearing that will not rust. Good for wet and washdown areas.
Top plate 2-3/8 x 3-5/8 in
The flat plate that bolts under your cart. Measure your current plate to check the fit.
Overall height 4-3/4 in
From the floor to the top of the plate. Your cart sits this much higher.
