A set of 4 safely carries up to 1,050 lb total.
We count 3 casters to be safe, since one can lift off uneven floors.
- Ships in 1–3 business days.
- 30-day easy returns
- Expert help, 920-204-6816.
Specifications
- Wheel material
- Phenolic
- Wheel diameter
- 5 in
- Wheel width
- 1-1/4 in
- Bearing
- Plain with stainless top hat bushings
- Capacity
- 350 lb per caster
- Overall height
- 6-1/8 in
- Mounting
- Top plate
- Top plate size
- 2-3/8 x 3-5/8 in
- Bolt hole pattern
- 1-3/4 x 2-7/8 in, slotted to 3 in
- Attaching bolt size
- 5/16 in
- Finish
- Stainless
What these specs mean
Phenolic
A hard resin wheel that rolls easily under heavy loads on smooth floors. Shrugs off oil and grease.
Plain with stainless top hat bushings
A simple bearing for light loads that move now and then.
Top plate 2-3/8 x 3-5/8 in
The flat plate that bolts under your cart. Measure your current plate to check the fit.
Overall height 6-1/8 in
From the floor to the top of the plate. Your cart sits this much higher.
